Q6 Powerful Air Curtain Series

Q6 Powerful Air Curtain Series is a air curtains option for restaurants, retail entrances, frequent door traffic and similar projects.

Start here

Start here when the project needs air curtains for restaurants or retail entrances. Confirm dimensions, voltage, access, controls, and current model documents before selecting an exact model.

Seriesproduct overview Air Curtainsproduct family Documentsmodel documents

Typical uses 3 checks Key inputs Door width / Mounting height / Heated or unheated / Voltage Product documents 1 available Request model documents Model review

Restaurants
Retail entrances
Frequent door traffic

Request model documents

Q6 Powerful Air Curtain Series product view 1

Q6 Series

Q6 Powerful Air Curtain

Powerful Q-series air curtain for restaurant and retail entrances where stronger discharge, indoor comfort, and frequent doorway traffic need review together.

Q6 Powerful Air Curtain should be reviewed around restaurant entrances, retail entrances, frequent door activity, mounting conditions, electrical service, controls, and access for installation or service.

Use the visible product photos and model reference image to start the comparison, then confirm release documents before quoting, submittal, certification language, or final project use.

Key specs

Airflow air volume 1800-4000 m3/h high speed; 1400-3200 m3/h low speed by model Project input Voltage Confirm the US voltage option Model check Mounting Surface-mounted entrance air curtain; mounting height 2.5-3.0 m Project input

Typical uses

Restaurant entrances
Retail entrances
Frequent door activity

Build notes

Restaurant and quick-service entrance positioning
Higher-velocity airflow path for frequent opening cycles
Low-profile design language for visible storefronts
Supplied model table lists 900 / 1000 / 1200 / 1500 / 1800 / 2000 mm lengths, 2.5-3.0 m mounting height, and 1800-4000 m3/h high-speed air volume by model

Check current model documents before quote or submittal use. Model data

Spec field	Selection value	Use boundary
Model number	Q6 Series	Model identifier
Airflow	air volume 1800-4000 m3/h high speed; 1400-3200 m3/h low speed by model	Project input
Voltage and phase	Confirm the US voltage option	Confirm by model
Power input	140-245 W high speed; 112-196 W low speed by model length; confirm voltage and exact model power	Confirm by model
Sound rating	50-54 dB high speed; 40-43 dB low speed by model length; installed sound depends on mounting conditions	Project input
Dimensions	900/1000/1200/1500/1800/2000 x 190 x 210 mm model sizes; confirm inch dimensions	Confirm by model
Weight	Confirm shipping and installed weight	Confirm by model
Mounting type	Surface-mounted entrance air curtain; mounting height 2.5-3.0 m	Project input
Controls	Confirm switch, sensor, and wiring package	Confirm by model
Warranty	Confirm warranty terms by product and sales channel	Confirm by model

Source parameter	Published source value	Selection use
Air volume	1800-4000 m3/h high speed; 1400-3200 m3/h low speed	Use as a source airflow range; confirm exact model data before submittal use
Air velocity	11 / 9 m/s high / low	Use as a source velocity reference; confirm exact airflow by model before submittal use
Motor power	140-245 W high speed; 112-196 W low speed by model length	Confirm voltage and exact model power before quotation
Noise level	50-54 dB high speed; 40-43 dB low speed by model length	Use as a source sound range; installed sound depends on mounting conditions
Available lengths	900 / 1000 / 1200 / 1500 / 1800 / 2000 mm	Match the unit length to finished door width before requesting documents
Mounting height	2.5-3.0 m	Check against finished opening height, header clearance, and traffic pattern

Equipment photos

Equipment views that change selection

Use the photos to confirm the visible form factor, access side, mounting details, and service points before reading the longer selection notes.

Q6 Powerful Air Curtain Series equipment detail 1 — **Product view**Review the form factor here; confirm performance and documents separately.

Typical uses

Review doorway width, clear opening height, traffic pattern, wind exposure, and whether the entrance is retail, restaurant, cold-room, or service-door use. Treat a restaurant entrance air curtain with frequent door traffic as a separate review from a cold-room or low-traffic interior opening.

Selection boundary

Review this series when the project needs a surface-mounted door air curtain. Move to another series when the opening needs a different motor class, heated construction, recessed mounting, cold-storage duty, or wider industrial coverage.

Installation review

Check header clearance, bracket position, electrical access, door sensor expectations, and discharge direction before treating the model as ready for ordering. Photos of the doorway usually improve the first review.

Parameter reading

Read airflow, velocity, sound, width, voltage, and control notes together. A door-width match alone is not enough when comfort, insect control, heating, or cold-room separation is part of the decision.

Sizing Inputs

Open doors create comfort complaints, insect entry, dust movement, and temperature swings that need doorway-specific review.

Start with the visible model cards above, then collect the few site conditions that change equipment fit before requesting final model documents.

Start with finished door width, finished door height, and mounting height.
Confirm whether the opening is indoor-to-outdoor, conditioned-to-unconditioned, or cold-room service.
Review voltage, heating preference, control method, and available mounting space before model selection.

Door widthMounting heightHeated or unheatedVoltageAir velocity or airflow dataSound rating where available
