Air Curtains

E Air Curtain Series

E Air Curtain Series is a air curtains option for commercial entrances, distributor programs, taller openings and similar projects.

Start here

Start here when the project needs air curtains for commercial entrances or distributor programs. Confirm dimensions, voltage, access, controls, and current model documents before selecting an exact model.

Seriesproduct overview Air Curtainsproduct family Documentsmodel documents
Typical uses 3 checks Key inputs Door width / Mounting height / Heated or unheated / Voltage Product documents 1 available Request model documents Model review
  • Commercial entrances
  • Distributor programs
  • Taller openings
Request model documents

Series options

Compare E Air Curtain Series options

Check photos, key specs, typical uses, and document needs before requesting current model documents.

E Air Curtain equipment view

E Series

E Air Curtain

E series centrifugal air curtain for commercial entrances with width options from 900 mm to 2000 mm and 3.5-4.0 m or 4.0-5.0 m mounting-height ranges by model.

E Air Curtain should be reviewed around commercial entrances, distributor programs, taller doorway selection, mounting conditions, electrical service, controls, and access for installation or service.

Use the visible product photos and model reference image to start the comparison, then confirm release documents before quoting, submittal, certification language, or final project use.

Key specs
Airflow Air velocity 17 / 14 m/s high / low or 21 / 18 m/s by model; confirm exact model before submittal use Model check Voltage Confirm the US voltage option Model check Mounting Surface-mounted centrifugal unit; installation height 3.5-4.0 m or 4.0-5.0 m by model Project input
Typical uses
  • Commercial entrances
  • Distributor programs
  • Taller doorway selection
Build notes
  • 900-2000 mm width range from the supplied product text
  • Centrifugal turbo design for higher air velocity and pressure than cross-flow models
  • Galvanized steel housing with powder coating details from the supplied product text
  • Use model documents before publishing cold-storage or energy claims
Check current model documents before quote or submittal use. Model data

Technical parameters

E Air Curtain technical parameters

The first model table shows how to read available values before final confirmation on the exact model page.

Spec field Selection value Use boundary
Model number E Series Model identifier
Airflow Air velocity 17 / 14 m/s high / low or 21 / 18 m/s by model; confirm exact model before submittal use Confirm by model
Voltage and phase Confirm the US voltage option Confirm by model
Power input 345-1036 W by model length; confirm voltage and exact model power Confirm by model
Dimensions 900/1200/1500/1800/2000 mm available lengths; confirm inch dimensions Confirm by model
Weight Confirm shipping and installed weight Confirm by model
Mounting type Surface-mounted centrifugal unit; installation height 3.5-4.0 m or 4.0-5.0 m by model Project input
Warranty Confirm warranty terms by product and sales channel Confirm by model

Model table

E Centrifugal Air Curtain Source Parameters

Source parameterPublished source valueSelection use
Air velocity17 / 14 m/s high / low or 21 / 18 m/s by modelUse as a source velocity range; confirm exact model before submittal use
Installation height3.5-4.0 m or 4.0-5.0 m by modelCheck whether the doorway belongs in the standard or taller-door range
Motor power345-1036 W by model lengthConfirm voltage and exact model power before quotation
Available lengths900 / 1200 / 1500 / 1800 / 2000 mmMatch the unit length to finished door width before requesting documents

Equipment photos

Equipment views that change selection

Use the photos to confirm the visible form factor, access side, mounting details, and service points before reading the longer selection notes.

E Air Curtain Series equipment detail 1
Product viewReview the form factor here; confirm performance and documents separately.

Applications

Applications

For submittal documents or current model documents, prepare door dimensions, mounting height, voltage, heated or unheated preference, controls, quantity, and any certification or document requirement by exact model.

Typical uses

Review doorway width, clear opening height, traffic pattern, wind exposure, and whether the entrance is retail, restaurant, cold-room, or service-door use. Treat a restaurant entrance air curtain with frequent door traffic as a separate review from a cold-room or low-traffic interior opening.

Selection boundary

Review this series when the project needs a surface-mounted door air curtain. Move to another series when the opening needs a different motor class, heated construction, recessed mounting, cold-storage duty, or wider industrial coverage.

Installation review

Check header clearance, bracket position, electrical access, door sensor expectations, and discharge direction before treating the model as ready for ordering. Photos of the doorway usually improve the first review.

Parameter reading

Read airflow, velocity, sound, width, voltage, and control notes together. A door-width match alone is not enough when comfort, insect control, heating, or cold-room separation is part of the decision.

Sizing Inputs

Open doors create comfort complaints, insect entry, dust movement, and temperature swings that need doorway-specific review.

Start with the visible model cards above, then collect the few site conditions that change equipment fit before requesting final model documents.

  • Start with finished door width, finished door height, and mounting height.
  • Confirm whether the opening is indoor-to-outdoor, conditioned-to-unconditioned, or cold-room service.
  • Review voltage, heating preference, control method, and available mounting space before model selection.
Door widthMounting heightHeated or unheatedVoltageAir velocity or airflow dataSound rating where available
